Circuit breaker 3kA PH Plus N16A
€11.11
Tax Included
(9.26 € HT)
Référence DEBFLEX : 707503
Emplacement magasin : B2-G-092
Circuit breaker Phase + Neutral DEBFLEX. Circuit breaker 3kA PH Plus N16A reference 707503.
Safety guarantees(to be modified in the "Reinsurance" module)
Delivery policy(to be modified in the "Reinsurance" module)
Returns policy(to be modified in the "Reinsurance" module)
Circuit breaker 3kA PH Plus N16A DEBFLEX reference 707503
General description
- Commercial range: MODULAR PROTECTION
- Function: Circuit breaker
- Full designation: Circuit breaker Ph+N 16A
- Rail System Mounting: DIN
- Color: White / Grey
Technical specifications
- Rated operating voltage Ue : (V) 230V
- Rated current In: (A) 16A
- Rated frequency: (Hz) 50Hz
- Nature of the current : Alternating
- Total number of poles: 2
- Number of protected poles: 1
- Rated insulation voltage Ui : (V) 400V
- Rated impulse withstand voltage Uimp : (V) 4000V
- Instantaneous trip characteristic C
- Reference calibration temperature: (°C) 30°C
- Rated differential breaking capacity: 3000A
- Rated short circuit current: 3000A
- Breaking capacity of a single pole: 3000A
- Triggering mode: Magnetothermal
- Energy limitation class (I²t): 1 Grid distance (short circuit test): 55mm
- Type of protection against external influences: Closed
- Type of terminals: Screw
- Diameter of the terminal screws 4mm
- Material of the terminals: Zinc plated steel
- Wiring plan : Yes
Environmental characteristics
- Operating temperature (°C) : -5°C to 50°C
- Waterproofing level: IP20
- Shock resistance: 850°C
- Fire resistance : Yes
- UV resistance : Yes
- Storage temperature 25°c
Standards, approvals and contracts
- Warranty : 2 years
- CE certification : Yes
- NF certification : Yes
- Reference standard: EN 60898
- ROHS : Compliant
Reference Debflex 707503 / DEBDI707503
Technical data
| Modular equipment | |
|---|---|
| Product range | Modular protection |
| Function | Circuit breaker |
| Intensity | 16 A |
| Number of poles | 1P+N Pole(s) |
| Connection | Screws |
| Switching capacity | 3 kA |
| Curve | C |
| Number of module(s) | 1 |
| Voltage | 230 V |
3 Items
Data sheet
- Weight (kg) :
- 0,1
- Amperage (A) :
- 16
- Warranty:
- 2 years
Specific References
- EAN13
- 3142187075031
- EAN-13
- 3142187075031
- Location
- B2-G-092
- Reference to display
- DEBDI707503
- Supplier reference
- 707503
