BDR-CDS100 100l wall-mounted double-jacket reheating tank
€973.22
Tax Included
(811.02 €HT + Ecotaxe €14.30HT)
Prix public: 958.92 € TTC (799.10 € HT)
Référence Ariston : 3070583
Emplacement magasin :
BDR-CDS100 100l wall-mounted double-jacket reheating tank
STYX: 3070583
Safety guarantees(to be modified in the "Reinsurance" module)
Delivery policy(to be modified in the "Reinsurance" module)
Returns policy(to be modified in the "Reinsurance" module)
Ring heat exchanger for the comfort of large numbers of people
- Models from 80 to 200 L, in combination with a gas or wood boiler.
- Wall or floor installation, vertical or horizontal.
- Tank protection: magnesium anode.
- Operate with pump or thermosiphon (without charge pump).
- Easy maintenance: 0105 mm flange.
- Thick polyurethane foam insulation.
- Large heat exchange surface.
- Sanitary loop (except 80 L).
- Built-in reversing thermostat.
- Electrical kits available with 230V power supply.
- Optional electric heater.
| GENERAL CHARACTERISTICS | ||
| DHW storage capacity Maximum storage tank temperature | L °C | 100 90 |
| Cooling constant | Wh/l.K.24h | 0.34 |
| Heat loss Ua | W/K | 1.40 |
| Maximum cylinder operating pressure | bar | 8 |
| HYDRAULIC MAKE-UP EXCHANGER | ||
| Exchange surface | m² | 0.7 |
| Heat exchanger power | kW | 13.9 |
| Maximum make-up temperature | °C | 90 |
| Maximum make-up operating pressure | bar | 3 |
| Relative height of the base exchanger from the | 0.9 |
2 Items
Data sheet
- Length (cm):
- 44
- Width (cm):
- 44
- Main color :
- White
- Volume (L) :
- 100
- Weight (kg) :
- 46
- Main materials :
- Bois
- Warranty:
- 2 years
- Batterie ou pile incluse :
- Non
Specific References
- EAN13
- 5414849704978
- EAN-13
- 5414849704978
- Location
- Reference to display
- CHCBA3070583
- Supplier reference
- 3070583
